Vivotek IB9360-H 2MP H.265 IR Outdoor Bullet IP Security Camera with 3.6mm Fixed Lens

Brand: Vivotek
Part Number: IB9360-H
Write a Review
Check other similar products:
Discontinued
  • Vivotek IB9360-H 2MP H.265 IR Outdoor Bullet IP Security Camera with 3.6mm Fixed Lens
  • Vivotek IB9360-H 2MP H.265 IR Outdoor Bullet IP Security Camera with 3.6mm Fixed Lens
  • Vivotek IB9360-H 2MP H.265 IR Outdoor Bullet IP Security Camera with 3.6mm Fixed Lens

? Help me pick a security camera

Technical Support Technical Support
3 Year Warranty 3 Year Warranty
  • Compression : H.265, H.264, MJPEG,
  • Field of View (Horizontal) : 81°Field of View
  • Lens Type : Fixed Lens
  • Lens Size : 3.6mm Lens
  • Sensor Size : 1/2.9" Sensor
  • Protection Code : IK10 IP66
  • Color : White
  • Environmental : Outdoor
  • Aperture : F2.0

Description

Vivotek IB9360-H 2MP H.265 IR Outdoor Bullet IP Security Camera with 3.6mm Fixed Lens

VIVOTEK's IB9360-H is a H.265 outdoor bullet network camera equipped with a 2-Megapixel sensor, enabling resolution of 1920x1080 at 30 fps. Featuring VIVOTEK SNV and WDR Pro technology, the IB9360-H is capable of capturing high-quality imagery in both high contrast and low light environments.

The IB9360-H deploys a 3.6mm lens and is equipped with IR illuminators with a 30-meter effective range for better night visibility. Further, to provide reliable coverage in harsh outdoor environments, the IB9360-H is encased in robust IP66 and IK10 housing.

By employing VIVOTEK's Smart Stream III technology and H.265 codec support, the IB9360-H is able to reduce bandwidth usage by up to 90%* while maintaining supreme image quality. Additionally, the VADP (VIVOTEK Application Development Platform) allows users to customize applications for the ever-expanding number of user scenarios in a diversifying surveillance market.

* Depending on scenes

Key Features:

  • H.265 Compression Technology
  • 30 fps @ 1920x1080 (WDR Pro on)
  • SNV (Supreme Night Visibility) for Low Light Conditions
  • WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
  • Smart Stream III to Optimize Bandwidth Efficiency
  • Built-in IR Illuminators, Effective up to 30 Meters
  • Trend Micro IoT Security
  • Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
  • Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
Replacement of: IB8369

Downloads

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

Aperture:
F2.0
Camera Style:
Bullet
Color:
White
Compatible Integration (API):
ONVIF Profile G ONVIF Profile S ONVIF Profile T
Compliance:
NDAA Compliant
Compression:
H.265 H.264 MJPEG
Day/Night:
ICR (True Day/Night)
Digital Zoom:
48
Durability:
Vandal Proof Weatherproof
Environmental:
Outdoor
Field of View (Horizontal):
81
IR LED Quantity:
2
Iris:
Fixed Iris
Lens Size:
3.6mm
Lens Type:
Fixed Lens
Max Power Consumption:
6.49 Watts
Minimum Illumination (B/W):
0 lux with IR illumination on
Minimum Illumination (Color):
0.065 lux at F2.0
Network Interface:
1x RJ-45 10M/100M Base-TX Ethernet
Night Vision Range (ft):
98
Operating Humidity:
0% to 90% RH
Operating Temperature:
-30 °C to 60 °C (-22 °F to 140 °F)
Power Supply:
PoE (IEEE 802.3af)
Processor (CPU):
Multimedia SoC (System-on-Chip)
Protection Code:
IK10 IP66
RAM:
256MB
Resolution:
2MP
S/N Ratio:
68 dB
SD Card Support:
SD Card Supported
Sensor Size:
1/2.9"
Shutter Speed:
1/5-1/32000s
Special Technologies:
Trend Micro IoT Security Vivotek Stratocast Vivotek SNV (Supreme Night Visibility)
Technology:
Network (IP)
Warranty:
3-year Manufacturer Warranty
Web Browser:
Chrome Internet Explorer
Wide Dynamic Range (WDR):
True WDR 120dB
