Product Type | Mini Dome |
Maximum Resolution | 2MP |
Product Application | People Counting |
Application Environment | Indoor |
Image Sensor | Progressive Scan CMOS |
Sensor Size | 1/2.8 " |
Effective Pixels | 1944(H) X 1224(V) (2.38 MP) |
Day / Night | Yes |
Low Light Sensitivity | Superior |
Minimum Illumination | Color: 0.1 lux at F2.2 (30 IRE, 2400 K); B/W: 0 lux at F2.2 (IR LED on) |
Mechanical IR Cut Filter | Yes |
IR Sensitivity Range | 700-1100nm |
IR LED | Adaptive IR LED x 3 (855 nm) |
IR Working Distance | 15m |
Horizontal Resolution (TV Lines) | 1100 TVL |
S/N Ratio | 56 dB |
| | |
Focal Length | Fixed focal, f2.55mm |
Aperture | F2.2 |
Iris | Fixed iris |
Focus | Fixed focus |
Lens Mount | Board mount |
Horizontal Viewing Angle | 110.3° |
Vertical Viewing Angle | 62.7° |
| | |
Compression | H.264 (Baseline/ Main/ High profile), MJPEG |
Maximum Frame Rate vs. Resolution | 60 fps at 1920 x 1080
60 fps at 1280 x 720
30 fps at 640 x 480
30 fps at 320 x 240 |
Multi-Streaming | Simultaneous triple streams based on three configurations |
Bit Rate | 128Kbps - 12Mbps (per stream) |
Bit Rate Mode | Constant, Variable |
Wide Dynamic Range | Extreme WDR (145 dB) |
Image Enhancement | Digital Image Stabilizer (DIS, EIS), Defogging |
Digital Noise Reduction | 2D + 3D DNR |
Privacy Mask | 4 configurable regions |
Built-in Analytics | Object Line Counting, Object Based Motion Detection, Tampering Detection |
Server-based Analytics | Object Line Counting, People Counting, Face Detection, Object Based Motion Detection, Tamper, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Smoke Detection, Heat Map, Dwell Time, People Queue Detection, (Require PC-based or standalone IVS or ALPR Server. Contact ACTi support for recommendations on how to maximize analytical accuracy) |
Image Orientation | Rotation |
IVS performance | Certain algorithms may require more computing power, which may limit the number of algorithms that can be concurrently used in the camera. Please test the actual performance before using in a project. |
| > | |
Network Protocol & Service | IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X |
Ethernet Port | 1 x RJ-45 connector |
Security | IP address filtering, HTTPS encryption, Password protected user level, Anonymous login, IEEE 802.1X network access control |
| | |
| | |
Event Trigger | Video motion detection (10 regions), Intelligent event detection |
Event Response | Notify control center, Change camera settings, Command other devices, E-mail notification with snapshots, Push notification to mobile device, Upload video to NVR server, Upload video or snapshot to FTP server |
| | |
Unified Solution | Fully compatible with ACTi software |
GPS Position | Manual setting |
ONVIF Compliant | Yes, Profile S, Profile G |
Web Browser | IE 11 |
Auto Firmware Upgrade | Yes |
| | |
Local Storage | MicroSDHC, MicroSDXC memory card slot (card not included) |
| | |
Power Source | DC 12V, PoE Class 2 (IEEE802.3af) |
Power Consumption | 5.6 W (PoE, IR on), 4.2 W (DC, IR on) |
Weight | 232g (0.511lb) |
Dimensions | (Ø x H): 115mm x 30.02mm (4.5" x 1.2") |
Mount Type | Surface, Gang Box, Pendant, Converter for NPT Standard Mounts |
Starting Temperature | -10°C ~ 50°C (14°F ~ 122°F) |
Operating Temperature | -20°C ~ 50°C (-4°F ~ 122°F) |
Approvals | CE, FCC, UL (for optional PoE injector and power adapter) |
Warranty | 3 Year(s) |
